3.Quick Review
3
3. Quick Review
3.1 Panel and Interface
3.1.1 Front Panel
1
11
10
9
8
3
6
7
2
5
4
Figure 3-1 Front Panel Overview
1
Display Area
Display user interface.
2
Current Key
Set current parameters, press to move the cursor when
editing parameters
3
Knob
Select the main menu or change the value, function
equals to the confirmation key.
4
Over Current
Setting Key
Set over current protection parameters, press to move
the cursor when editing parameters
