Setting shown above can fluctuate.
After applying the settings, test the machine.
The user is responsible for any incorrect planting process.
Chickpea Seeds (Big Size)
FAN (VACCUMETER SETTING)
Manometer should be arranged
around 60 bars.
remove
SEED SCRAPER
ATTENTION: REMOVE!!!
This tool will not be used.
Remove the tool shown in the
figure.
SEEDING COULTER
For Chickpea seeds, coulter depth
should be (8,5 cm).
8,5 cm
CONSIDERATIONS
1.The seeds to be used for plantation process must be dry.
2. Humid or wet seeds must not be used.
3. Sometimes seeds are wetted and are coated with a wet layer of medicine to protect
them. while planting these seeds, medicine on them sticks to the holes of the disc
and act as an obstacle for turning of the discs. So, seeding distance and seed planting
process are affected.
CHICKPEA and PEANUT PROTECTION PLASTIC
Protection plastic MUST BE ATTACHED.
Otherwise, mixer nails of the disc will be damaged.
Note: While mounting this plastic, first remove the 2.5
Allen head bolts and then put the bolts for this part.
attach
61
