2. LOADING NAILS 3. CONTROLS
OPERATION
The tool is recommended for use with a residual current
device with a rated residual current of 30mA or less.
1. Hold the tool upside down.
2. Squeeze the magazine latch and pull the magazine out of the
tool.
3. Insert a row of nails
into the opening
behind the nose
piece. Be sure to
align them to the
side marked with a
nail marker.
4. Push the loaded magazine back into the unit until it clips into
place.
1. To supply the tool with
power, push the power
switch to the “I” position.
3. To re the staple
nail gun, squeeze
the on/off trigger.
2. To turn off, push the
power switch to the
“O” position.
