Ozone Rush 3 - Page 53

51
RISER DIAGRAM / LENGTHS (mm)
Non Accelerated
Accelerated
A 500
B 500
C 500
A 350
B 383
C 500
TECHNICAL SPECIFICATIONS
No. of Cells 51 51 51 51 51
Projected Area (m2) 19 20.8 22.5 24.5 27
Flat Area (m2) 22 24 26 28.3 31.2
Projected Span (m) 8.86 9.25 9.63 10.05 10.55
Flat Span (m) 11 11.49 11.96 12.48 13.1
Projected Aspect Ratio
4.12 4.12 4.12 4.12 4.12
Flat Aspect Ratio 5.5 5.5 5.5 5.5 5.5
Root Chord 2.54 2.65 2.76 2.88 3.02
Glider Weight (Kg) 5.2* 5.4* 5.6 5.8* 6*
In-Flight Weight Range 55-75 70-90 85-105 100-120 115-130
Certication EN/LTF B B B B B
XS
S
M L
To be confirmed
*
XL
