Ozone Rush 4 - RISER DIAGRAM; LENGTHS (mm); TECHNICAL SPECIFICATIONS

RISER DIAGRAM / LENGTHS (mm)
57
Non Accelerated
Accelerated
Pulleys axis - axis
A 500
B 500
C 500
A 350
B 400
C 500
TECHNICAL SPECIFICATIONS
No. of Cells 57 57 57 57 57 57
Projected Area (m2) 18.0 20.1 21.2 22.3 23.7 26
Flat Area (m2) 21.4 23.8 25.1 26.5 28.1 30.8
Projected Span (m) 8.55 9.02 9.27 9.51 9.78 10.25
Flat Span (m) 10.09 11.51 11.82 12.13 12.48 13.08
Projected Aspect Ratio
4.05 4.05 4.05 4.05 4.05 4.05
Flat Aspect Ratio 5.55 5.55 5.55 5.55 5.55 5.55
Root Chord (m) 2.47 2.61 2.68 2.75 2.83 2.97
Glider Weight (Kg) 4.9 5.2 5.5 5.7 6.0 6.3*
Max Control Travel (cm)
74
74 75 74 74 75
In-Flight Weight Range (Kg) 55-70 65-85 75-95 85-105 95-115 110-130
Certication EN/LTF B/B* B/B* B/B* B/B* B/B* B/*
XS
S MS L XLML
*To be confirmed
