Control Input:
The OzotechEOG PCB is activated to produce ozone when a pilot
input signal is applied across “+” & “pilot” terminals.
Auxiliary Output Functions:
The NO/NC auxiliary outputs have a 3 second o-delay, after the
pilot signal is shut o. These outputs are capable of outputting a
maximum of 60mA @ 70°F and are intended to be used as a control
circuit only. Attach positive wire to NO or NC output terminal, and
negative wire to GND terminal to complete the desired circuit. See
gure 1, on page 14 for auxiliary output locations.
Fusing:
The control PCB is equipped with automatically resetting on-board
fuses. If these fuses trip, due to a short of the HV transformer,
excessive load on the auxiliary output(s), remove excessive load/
cause of short, and cycle main power on/o to reset. If the HV
transformer is shorted, the LED indicator will stay solid red until
condition is remedied. If either NO or NC output is active and
experiences excessive load, the LED indicator will quickly ash red
until condition is removed.
4.3 Operation Continued
8.
