Programming mode
When 1-EASY type is selected, the displaying of the programming windows PROG2, PROG3 and PROG4 are
no longer available to the user.
Window PROG1 also, in MODO_TEST5 and MODO_TEST10 mode, changes in that only 3 parameters remain
active:
Where: gg/mm/aa = Current date
hh:mm = Current time
xxx = Nominal voltage of battery in Volt (2-120)
bbbb = Nominal capacity of battery in Ah (10-3200) from where the discharge current is
obtained in Ampere (1-160) by means of ratio Ah/5 (TEST5) or Ah/10 (TEST10)
nn = Numberof charge+discharge cycles to perform (0-99)
TESTXX = Discharge mode (see par.4.1) not amendable
Duration of fixed discharge phase = 5 hours
STOP voltage in fixed discharge equal to 1.70 V/el. (1.02V/el for NiCd)
It is possible to access the PROG4 window from PROG1 window, to eventually return to 0-FULL mode, by
pressing the SET key.
SETTING OF MODES OF OPERATION
In the PROG 1 window the modoc parameter can be set to:
Table G.1 Battery test mode description and parameters settings
THE HIGHLIGHTED FIELDS CANNOT BE MODIFIED
MODOC DESCRIZIONE
ISCAR
(A)
TS
(h:m)
VST
(V/el)
TCmin
(h:m)
TCmax
(h:m)
TPCar
(h:m)
TPScar
(h:m)
TEST Test liberi Ahnom/5 5:00 1.70 3:00 24:00 1:00 0:30
CICLI Cicli liberi Ahnom/5 5:00 1.85 0:01 2:00 0:05 0:02
TEST5 Test 5h fissi Ahnom/5 5:00 1.70 3:00 24:00 1:00 0:30
TES10 Test 10h fissi Ahnom/10 10:00 1.70 3:00 24:00 1:00 0:30
C+T5
N-1 cicli liberi + Ahnom/5 5:00 1.85 0:01 2:00 0:05 0:02
1 Test 5h fisso
(car + scar + car)
Ahnom/5 5:00 1.70 10:00 16:00 1:00 0:30
C+T10
N-1 cicli liberi + Ahnom/10 10:00 1.85 0:01 2:00 0:05 0:02
1 Test 10h fisso
(car + scar + car)
Ahnom/10 10:00 1.70 10:00 16:00 1:00 0:30
CONSTI
Only CONST.
CURRENT
DISCHARGE
RatAh/5 5:00 1.85 0:01 2:00 0:05 0:02
CONSTV
Only CONST.
VOLTAGE
DISCHARGE
RatAh/5 **:** RatV 0:01 2:00 0:05 0:02
General operation features:
a) When connecting a new battery, its current capacity is made equal to the set rated value.
b) Before starting a test cycle (i.e. while still in the START mode), and provided that a battery is
connected, the current battery capacity can be set by pressing SET.
Every time a button is pressed, the battery capacity increases by 10% up to the limit RatAh value. On
exceeding the limit value, the system returns to 0%.
c) If the No. modoc cycle number is set to 0, only is a single discharge performed, irrespective of the
current battery capacity.
gg/mm/aa hh:mm PROG1
Vnom=xxxV Ahnom=bbbb
N.TESTXX=nn
