P. 8
MaxCT = Maximum charge time (if this time is exceeded, a charge fault is reported)
MinCT = Minimum charge time
Mag = Charge increase
PTaC = Time pause after charge
PTaD = Time pause after discharge
StD = Time of diagrams sampling
When pressing PRG ,
the system enters the PROG 3 window:
It is now possible to set:
gg/mm/aa = current date
hh:mm = current time
b………b = Battery Identification Code (16 characters)
n………n = Generic Notes field (32 characters)
When pressing PRG ,
the system enters the PROG 4 window:
Where: x-aaaa = Type of connected battery (0-Pb, 1-NiCd) (FW of V1.31)
y-bbbbbbb = Displaying mode of the programming pages (0-FULL,1-EASY)
(FW of V1.32)
The parameters values can be varied using the control panel keys.
In particular
Esc key : exits programming and returns to START window
à key : increases the selected value
¹ key : recalls the time programming
← key : moves the parameter selection to the left
PRG key : exits the programming pages
→ key : moves the parameter selection to the right
C key : recalls the minimum selected value (FW v. 1.03)
õ key : decreases the selected value
OK key : confirms the selected value, memorises it and moves cursor forward
After 2 minutes of inactivity of the buttons, exit and returns to START state (as for Esc key).
Battery type setting
When 1-NiCd type is selected, the nominal voltage of an element is brought from 2.0V to 1.2V with display of
one decimal.
All thresholds in V/el. Are recalculated based on fixed ratio 0.6.
Parameter 0-Pb 1-NiCd U.M.
Vnom 12 12.0 Volt
VStop 1.70 1.02 V/el.
Vgas 2.40 1.44 V/el.
gg/mm/aa hh:mm PROG3
IDB=bbbbbbbbbbbbbbbb
Notes:nnnnnnnnnnnnnnn
nnnnnnnnnnnnnnnnn
TIPO B.=x-aaaa PROG4
MODO PROG.=y-bbbbbbb
