Recording settings
The receiver is set from the factory to record for 24 hours on all channels.
1. Enter the main menu and select [Record].
2. Select channel and select the desired type of recording (constant or motion-
controlled). The desired time frame can be set in two ways:
• Hold down the mouse in the chart and drag the cursor to the desired period.
There can be a total of 6 fixed time periods, where the system will automatically
record.
• Click and enter the desired recording time.
Instant playback
1. Clicking anywhere on a channel view with the mouse will automatically open a
checkbox underneath the channel.
2. Click to play the first 5 minutes of the video in question.
