11
2.3 Attach the upper handle to the lower handle by inserting the bolt (1).
2.4 Place the plastic over the bolt washer ensuring the curve of the washer sits on the
curve on the handle bar (2).
2.5 Secure in place using the large locking wheel (3).
2.6 Lift the rear discharge flap to expose the grass bag support bar (1).
2.7 Using the hooks on the grass bag, hook the grass bag over the bar at the rear of the
lawn mower (2).
2.8 Lower the rear discharge flap until it rests on the grass bag (3).
