3.17 Place the lawn mower on a flat level surface (1).
3.18 Unscrew and remove the dipstick (2).
3.19 Slowly fill with approx. 600ml of Semi-Synthetic SAE15W40 engine oil (1) to the upper
level mark on the dipstick (2).
3.20 DO NOT OVERFILL stop occasionally to check the oil level.
3.21 Once full, refit the dipstick securely.
3.22 If you do overfill, you can remove some oil by gently tiling the machine on its side and
pouring the excess oil into a suitable container.
