32
NOTE
Before use you MUST check and if necessary, adjust the Operator Presence Control
(OPC) cable.
If the cable is too loose, the lawn mower will not start.
There should be no more than 10mm free play in the OPC cable.
To check, start to pull the OPC lever towards the main handle.
The OPC cable should start to move within 10mm of pulling the handle.
3.27 If adjustment is required, trace the OPC cable down from the handle to the engine of
the lawn mower, until you reach the OPC cable adjuster (1).
3.28 Undo the lock nut (2) and wind it forwards (3).
3.29 Wind the adjuster nut towards the lock nut.
As you adjust, keep checking the tension on the OPC cable until the desired tension
is reached.
3.30 Tighten the lock nut back towards the adjuster nut (2) and then attempt to start the lawn
mower.
3.31 If the lawn mower starts, tighten both nut securely.
If not, repeat the process until the lawn mower will start.
