NOTE
Selector (the transmission) must be in
N (Neutral) to start the truck.
Neutral Mode
• Selects Neutral.
• Initial Gear position after Start-Up.
WARNING
Apply parking brake and follow vehicle
manufacturer parking instructions. Fail-
ure to follow these instructions could
cause unintended vehicle movement re-
sulting in death, serious injury or dam-
age to property.
NOTE
When attempting to start the engine and
the engine does not crank, confirm Neu-
tral is selected, vehicle parking brake is
applied and service brake is depressed.
Reverse Mode
• Reverse mode selects the default
Reverse gear.
NOTE
If the driver attempts to select a non-
neutral mode without depressing the
service brakes the transmission will not
shift into gear and you will have to return
to Neutral and depress the service
brakes before selecting the desired
mode again.
• Each time Reverse is selected from
Neutral, the default Reverse gear is
engaged.
Drive Mode (Auto Mode)
• Intelligent Start Gear Selection will
automatically select the start gear
depending on inputs such as, load,
grade, and axle/transmission ratio.
This start gear can be changed by
using the up/downshift request
procedure, as long as the selection
still falls into a gear that would
allow the vehicle to launch without
causing damage to the
transmission.
NOTE
If the driver attempts to select a non-
neutral mode without depressing the
service brakes the transmission will not
shift into gear. The driver must re-select
Neutral and depress the service brakes
before selecting the desired mode
again.
• If the start gear is changed using
the up/downshift request
procedure, it will remain as the
default until the vehicle is powered
down or the selection is changed.
However, conditions such as,
grade, may still override the default
start gear selection.
• A shift can be advanced by using
the up/downshift request procedure
when the transmission is near the
shift point.
DRIVING - Drive Neutral Reverse Selector
14 Y53-1272-1B1 (08/17)
