MX-11 Engine Accessory Drive Belts
4
5
3
1
2
7
6
1. Accessory belt
2. Fan belt (not present with crank mounted fan on T680MLU
MX-11 and LHP MX-13)
3. Water pump
4. Tensioners
5. Engine dampener
6. A/C compressor
7. Alternator
ENGINE MAINTENANCE - Maintenance Procedures
Y53-1166-1M1 (10/2020) 87
