Part no. Descripon Images
Electrical
M-250B
Light blub (OSRAM Halogen DC24V 20
Watt)
M-SEAL
Wire plastic seal connector
MEG-PUMP-220
Pump (220/380V)
MEG-PUMP-480
Pump (400-480V)
MEG-FPC
Female pump connector
MEG-MPC
Male pump connectors
MEG-AM1
Ammeter set-up kit
MEG-R
Rectifier
