MEGA-T300 Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Part no. Descripon Images
Electrical
M2-SAFE-B
MEGA M250 Safety lock out switch
(bottom piece)
M2-SAFE-K
Safety key
MEG-RL1
RL1 switch (24 V)
RELAY-B
24V relay base
GTB
Ground terminal block
TB
Terminal block
MEG-LITE
Light housing
