MEGA-T300 Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Part no. Descripon Images
Mechanical-table
M3-TG
MEGA-T300 Table feed guide rods (pair)
M3-BOOT
MEGA-T300 Table feed boot
M3-TFW
MEGA-T300 Table feed wheel
T3-M-013
MEGA-T300 Table feed screw
T3-M-014
MEGA-T300 T-slot table
T3-M-015
MEGA-T300 wheel feed locking lever
T3-M-016
Table feed rail guide plate
