MEGA-T300 Abrasive Cutter
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
Part no. Descripon Images
Mechanical-table
T3-M-017
Table feed back screw cover
T3-M-018
Table feed rail guide block
T3-M-019
Table feed sliding rail guide
T3-M-020
Screw feed casting base outside cover-wheel
T3-M-021
Screw feed casting base inside cover
T3-M-054
Screw feed drive outside guide for table
T3-M-022
Screw feed drive inside guide for table
T3-M-023
Screw feed table wheel cover
