- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - INSTRUCTION MANUAL
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
NANO 2000T Polisher
Part no. Description Images
Electrical
RELAY-B
24 volt relay switch base
NANO-R
Rectifier
N1-009b
Solenoid Valve (24 V)
CORD-110V
110V power cord
CORD-220R
220V round time power cord
CORD-220F
220V three prop flat connector
28
