Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
NANO 2000T Polisher
Programming mode
Water
switch
8
4.0 Start-up and Operation
4.1 General
4.2 Control Panel
The NANO 2000T is a hand grinding/ polishing machine. By adding the FEMTO power head,
semi-automated polishing can be accomplished.
Emergency stop button: Emergency stop switch cuts power to the motor immediately.
Wheel direction: Clockwise rotation or counter clockwise rotation.
Start / stop buttons: Start/stop the polishing wheel in both manual and auto mode.
Water switch: Activates the water solenoid for the rinse bowl and rinse spout.
Preset speeds: Allows for faster speed control, SPL - low speed, SPM - medium
speed, SPH - high speed (factory setting approx. 100, 200, 300
rpm.
Auto-mode: Allows for running pre-programmed speeds and times (factory
setting approx. 200 rpm, FWD, 30 seconds).
Wheel direction
Start/Stop
Preset speeds
(Low, medium, high)
Auto-mode for timed
grinding/ polishing
