Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
NANO 2000T Polisher
Part no. Description Images
Mechanical Components
N12-002
NANO 1200 Polishing Table Support
Platen
N1-002PEG
Table support PEG's without o-rings
(3/set)
N1-002-O-Ring
Table support PEG O-ring (3/pkg)
N1-003S
NANO 1000T/2000T Spindle assembly
N1-025
FEMTO 1100 post collar (mounts on the
NANO 1000-2000 polisher)
N1-003P
NANO 1000-2000 Pulley wheel for
spindle wheel
N1-006
NANO 1000-2000 Pulley for motor
