- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL

3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com

Please read this instruction manual carefully and follow all installation, operating and safety guidelines.

NANO 2000T Polisher

Part no. Description Images

Mechanical Components

N12-M-002

NANO 1200 Spindle

N12-M-004

NANO 1200 Wheel pulley

N12-M-CR

NANO 1200 copper ring

N12-M-005

NANO 1200 Spindle shaft

N12-M-SSA

NANO 1200 Spindle shaft adapter

N12-M-RSH

NANO 1200 roller shaft housing
