- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1 520-882-6598 Fax +1 520-882-6599 email: pace@metallographic.com Web: http://www.metallographic.com
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
NANO 2000T Polisher
Programming Step Value Description
SP1 SPEED Disc Speed - VARIABLE
T1 TIME Runtime for SP1
SP2 to SP8 200 Multiple step disk speed - DO NOT CHANGE
T2 to T8 0 Runtime for multiple steps - DO NOT CHANGE
Cn 1 Number of cycles – DO NOT CHANGE
SL 100 Disc speed for SPL - preset to 100 rpm
SN 200 Disc speed for SPM - preset to 200 rpm
SH 300 Disc speed for SPH - preset to 300 rpm
DF Defaults—DO NOT CHANGE
U SET 110/220V—DO NOT CHANGE
ST 65 Shutoff motor temperature - DO NOT CHANGE
CT Current motor temperature - DO NOT CHANGE
CD1 0
Controlled by RUN/STOP button - DO NOT CHANGE
0: Front board control
1: External control of board
CD2 10
Display speed - DO NOT CHANGE
10: Displays speed (rpm)
11: Displays frequency (Hz)
CD3 Motor control method – DO NOT CHANGE
CD4 1000 Max. speed (rpm)
CD5 100 Min. speed (rpm) (do not go below 100 rpm)
CD6 15 Carrier wave value – DO NOT CHANGE
NANO 1000T/2000T and 1200T with 1 rpm increments (1 and 1.5 hp motor)
47
