8
PX013ANM / PX013ANC USER GUIDE Draft 140327b (501-34150XX)
CONNECTING THE EQUIPMENT (cont.)
Setup A - Home theater system with HDTV
(HDMI connection)
Setup A uses an HDMI connector to connect to the HDTV. This displays the highest quality picture on your HDTV and also means there will be no picture
degradation on any copy-protected programs (provided the link remains secure – see page 7).
OPTICAL
AUDIO IN
DIGITAL AUDIO IN
HOME
THEATER
RECEIVER
ANTENNA/
RF IN
HDMI
HDTV
CABLE INPUT
WALL AC OUTLET
NOTE
This diagram shows power cords that have 2-blade polarized plugs. You may need to use a different type of plug in the region where you live.
