14
WARNINGS
Do not connect your set-top box (or any other equipment such as a TV or VCR) to the power supply until you
have properly connected all the other cables.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
Connecting the power supply unit to your set-top box
Before you insert the power supply unit into the wall AC outlet, connect the 15 volt DC cord from the power supply
unit to the socket labeled “Power” on your set-top box’s rear panel.
Connecting equipment to the wall AC outlets
Connect your set-top box’s power supply unit, and the plugs on the power cords from your TV, DVD, and any
other equipment, into wall AC outlets. If these outlets have switches, switch them ON.
CONNECTING THE EQUIPMENT (cont.)
