To Next PageTo Next PageWhat causes excessive end play in shafts of my paladin Blower?
Excessive end play in the shafts (.005 inches [1.3mm] or more) of your paladin Blower when couplings are removed is caused by worn bearings. Remove gaskets between caps and the gear case; replace if necessary.
What to do if my paladin Sweepster M24 Blower brush head assembly “bounces” when sweeping?
If the brush head assembly of your paladin Blower is bouncing during sweeping, it could be due to several reasons: the brush pattern needs adjustment, the ground speed is too fast or the brush speed is too slow, or the core is bent. You can adjust the brush pattern, find the correct combination of ground and brush speeds, or replace the core to solve this issue.
What causes high internal operating temperature in my paladin Sweepster M24?
A high internal operating temperature (above 200ºF [93.33ºC]) in your paladin Blower can be caused by damaged bearings or a low oil level. To address this, replace the bearings or add oil.
What to do if my paladin Sweepster M24 Blower drive chain falls off repeatedly?
If the drive chain of your paladin Blower is repeatedly falling off, it could be because the core is not riding on the sprocket or there is not enough tension on the chain. Try aligning the core or sliding the core forward to increase chain tension.
What to do if my paladin Sweepster M24 electric lift does not lift?
If the electric lift on your paladin Blower is not working, check for disconnected wires and connect them. If the problem persists, the switch may have failed, requiring replacement. If necessary, replace the actuator as well.
Why gearbox of paladin Blower does not turn?
If the gearbox of your paladin Blower does not turn, it may be due to a broken shaft or gear. If the gearbox is still under warranty, do not open it; contact SWEEPSTER for replacement parts.
What causes shield tubes to be damaged on my paladin Blower?
Damaged shield tubes on your paladin Blower are caused by the shields contacting components on the tractor and/or sweeper. Allow more clearance and replace parts.
What causes shield tube to deform and split on my paladin Sweepster M24?
Deformation and splitting of the shield tube on one side of your paladin Blower is due to the shield tube being too short or having no overlap at all when the drive shaft is extended. Adjust the shield tube length and replace parts.
What causes inboard yoke ears to have pressure marks on my paladin Sweepster M24 Blower?
Pressure marks on the inboard yoke ears of your paladin Blower can be caused by an excessive bend angle when the shaft rotates or a drive shaft that is too long. Avoid running the brush in a raised position, switch off the tractor PTO during cornering or when lifting the brush head, and adjust the drive shaft length.
What to do if my paladin Blower hydraulic lift does not lift?
If the hydraulic lift on your paladin Blower is not lifting, check for disconnected hoses and connect them. If the issue persists, it may be due to hydraulic pump failure. Contact your dealer for service.
Instructions for installing the electric lift system.
Procedure for leveling the sweeper for optimal brush wear and performance.
Adjusting brush pattern and transport chain for proper operation.
Steps for operating the sweeper for effective debris collection.
Guidance for operating in various conditions like heavy debris, snow, and dirt.
Recommended maintenance tasks performed daily, at intervals, or when necessary.
Step-by-step guide for replacing worn brush sections.
Common problems and solutions for the brush head assembly.
Troubleshooting steps for gearbox malfunctions.
Solutions for problems with drive shafts and lift systems.
Steps to install the hydraulic angle kit on the sweeper.
Steps for installing the hydraulic lift kit.
Torque values for face seal fittings based on dash size and thread size.
Torque values for straight thread O-ring fittings to ports.
Details on product warranty, period, and conditions.
Specifies limitations and exclusions to the product warranty.
