Palazzani
Palazzani Industrie spa
OM 371 pag 4 Cap 3
distant from the machine
when the tracks are lowered on the ground, retract the telescope sections of
the stabilizr.
NB: If the ground is solid and resistant (pressed earth, cement, asphalt) the
operation is easy; on the contrary if the ground is yelding and irregular it is better
to drive the charriots on wooden plates.
- for the loading, lift the stabilisers from the boom side before and than balancing
them with the other two, and follow the procedure on the contrary.
- select now the controls key on “turntable” and transfer to the site with the
stabilisers up (min 10/15 cm) for a better stability in case of strong asperities.
c) By using a ramp.
ATTENTION!! If you are using a ramp we recommend a max slope of 15° (about
25%) and to attack the ramp with the cage toward the climb. This is absolutly
necessari for the stability of the machine.
To attack the ramp, lift up the cage just the necessary to avoid the ramp and not
more, like showed in the following picture. (To lift up the cage, thus the main
boom, see chap. 3.9)
Warning! During the transport on the lorry, bee sure that the locking rotation pin is
insert.
