Description Reason: Solution 1: Solution 2: Solution 3: Solution 4: Solution 5:
0
System OK / control system: OFF System OK / control system: OFF
System OK / control
system: OFF
1
System OK / control system: ON System OK / control system: ON
System OK / control
system: ON
2
Low voltage Voltage J1 pin 2 too low
Check J-1 & J-2 power
cable at PC board and
Battery for tight
connection, oxidation
and damage
Check the battery
condition / battery
charged
Motor could have worn
carbon brushes / motor
could be bad
Short in Cab Switch /On Off switch or
Aux port
Power consumption J11 pin 1 to high
Check J-1 & J-2 power
cable at PC board and
Battery for tight
connection, oxidation
and damage
8
General short General power consumption to high
Check J-1 & J-2 power
cable at PC board and
Battery for tight
connection, oxidation
and damage
Repair cables,
connections,check for burnt
crushed wires
9
Defect in motor solenoid during lifting. Power consumption J1 pin 3 too high
Check J-1 & J-2 power
cable at PC board and
Battery for tight
connection, oxidation
and damage
Check the battery
condition / battery
charged
Possible short in Thermo
switch inside motor :
Bypass and test , replace
Thermo switch
Fuse 15A damaged on power pack (J1
Pin2).
Check fuses at power
pack
Check fuse holder
replace fuse with
same amp fuse
b
Defective motor solenoid Power consumption J1 pin 3 too high
Check J-1 & J-2 power
cable at PC board and
Battery for tight
connection, oxidation
and damage
Check the battery
condition / battery
charged
Check ohm reading
of the coils
During operation , an error on the motor
solenoid
Power consumption J1 pin 3 too high
Check J-1 & J-2 power
cable at PC board and
Battery for tight
connection, oxidation
and damage
Check the battery
condition / battery
charged
Check ohm reading
of the coil motor
solenoid
P Error diagnostic mode active. Attached service plug - - - - -
TO CLEAR CODE :
UNPLUG J-11 AND PLUG BACK IN
PTV Circuit Board – M Control Fault Codes
