44
. Liftgates with Fixed Ramps have 10 grease fittings
. Liftgates with Aluminum Retention Ramp (ARR) have 12 grease fittings
. Use WD-40 or 0W20 motor oil on hinge points and Slide Pads if needed
Lubrication
CAUTION
DO NOT grease the Slide Pads or Columns or Runners, as this will VOID your
WARRANTY on the Slide Pads.
