Pall FP01087 Rev A User Manual

NL
44
Montage en Installatie instructies voor de
Pall
®
Multiple Application filter capsule
5. FIGUUR 1- MULTIPLE APPLICATION CAPSULE
FIGUUR 2 - MULTIPLE APPLICATION CAPSULE (EXTENDED)
6. EUROPESE RICHTLIJN 94/9/EC
Voor informatie betreffende Europese Richtlijn
94/9/EC (ATEX), gaarne bijlage 1 raadplegen.
Voor informatie betreffende Zone 0/20
toepassingen, gaarne contact opnemen met
de lokale Pall-vestiging of Pall distributeur.
‘Jaco’ ¼"/ 6 mm 90˚ Elbow
rDistance between the cent es of the 90° Elbow options
Ø
Distance between the centres of the 90° Elbow options
‘Luer Lok’ Compatible Vent
90
0
Elbow
Luer Lock compatible
Luer Lock compatible
PLC ‘CPC’ quick release
9 mm / 0,35"
21 mm / 0,83"
21 mm / 0,83"
16 mm / 0,62"
¼" Hose Barb
12 mm / 0,47"
9 mm / 0,35"
Jaco Tub e
Jaco ¼"/6 mm Tube
¼" NPT
Jaco ¼"/6 mm
90
0
Elbow
21 mm / 0,83"
26 mm / 1,02"
14 mm / 0,55"
14 mm / 0,55"
10 mm / 0,39"
15 mm / 0,59"
58 mm / 2,28"
74 mm / 2,91"
100 mm / 3,94"
58 mm / 2,28"
26 mm / 1,02"
141 mm / 5,55"
115 mm / 4,53"
