Pall FP01087 Rev A User Manual

EN
5
Assembly and Installation Procedures
Pall
®
Multiple Application Capsule filter assemblies
5. FIGURE 1 - MULTIPLE APPLICATION CAPSULE FILTER ASSEMBLIES
FIGURE 2 - MULTIPLE APPLICATION CAPSULE FILTER ASSEMBLIES (EXTENDED)
‘Jaco’ ¼"/ 6 mm 90˚ Elbow
rDistance between the cent es of the 90° Elbow options
Ø
Distance between the centres of the 90° Elbow options
‘Luer Lok’ Compatible Vent
6. EUROPEAN DIRECTIVE 94/9/EC
For information relating to European Directive
94/9/EC (ATEX), please refer to Appendix 1.
For information relating to Zone 0/20
Applications, please contact Pall.
90
0
Elbow
Luer Lock compatible
Luer Lock compatible
PLC ‘CPC’ quick release
9 mm / 0.35"
21 mm / 0.83"
21 mm / 0.83"
16 mm / 0.62"
¼" Hose Barb
12 mm / 0.47"
9 mm / 0.35"
Jaco Tub e
Jaco ¼"/6 mm Tube
¼" NPT
Jaco ¼"/6 mm
90
0
Elbow
21 mm / 0.83"
26 mm / 1.02"
14 mm / 0.55"
14 mm / 0.55"
10 mm / 0.39"
15 mm / 0.59"
58 mm / 2.28"
74 mm / 2.91"
100 mm / 3.94"
58 mm / 2.28"
26 mm / 1.02"
141 mm / 5.55"
115 mm / 4.53"
