PANEL DESCRIPTION
1
GROUND LIFT SWITCH
With the DMS you can interconnect two mains powered devices (for
example 2 mixers). This constellation can induce a ground loop hum.
Should this occur, use this switch to lift the ground of the second
output.
2
MOMENTAR Y SWITCH
With this footswitch you can toggle between the two outputs. Note
that the switch is momentary. When not pressed, Output 1 is active.
Output 2 is activated when you press and hold the switch. On re-
leasing the switch, Output 1 is active again.
3
INPUT
Connect your dynamic microphone or other balanced signal source to
this input.
4
OUTPUT 1
Active when footswitch is not pressed – Connect this output to the
microphone input of a mixer or similar device.
5
OUTPUT 2
Active when the footswitch is pressed and held – Connect this out-
put to the microphone input of a mixer or similar device.
