Install the ION 1200
Install Antennas
The ION 1200-C-NA, ION 1200-C-ROW, and ION 1200-C-5G-WW devices support multi-band
antennas which can be easily secured to the device. The ION 1200-C-NA and ION 1200-C-ROW
have three antenna SMA (F) connectors. The ION 1200-C-5G-WW has four antenna SMA (F)
connectors.
Feature Description
Antennas Multi–Band 4G / 5G Antenna
4G - 3x SMA Antenna connectors
5G - 4x SMA Antenna connectors
Frequency Range 615-960MHz / 1500-1600MHz /
1710-2690MHz / 3300-3700MHz
Peak Gain 2.3dBi in 800MHz band, 4.4dBi in 1575MHz
band, 2.6dBi in 2170MHz band, 1.7dBi in
3300MHz band, 3.8dBi in 4400MHz band
VSWR <3:1
Feed Impedance 50Ω
Power Handling 30 dBm
Interface SMA (F) Connectors
Antenna Dimensions 229 mm x 28 mm x 14 mm (L x W x T)
