Panasonic AJ-SD93 - Time Code

– 26 –
Setup menus (continued)
USER menu <TIME CODE>
The underlined items indicates the initial setting.
No./Item Description
506
BINARY GP
This sets the usage status of the
user bit of the time code generated
by the TCG.
0000
000 :
NOT SPECIFIED (character set not
specified)
0001 001 :
ISO CHARACTER (8 bits character
set based on ISO646, ISO2022)
0002 010 :
UNASSIGNED 1 (undefined)
0003 011 : UNASSIGNED 2 (undefined)
0004 100 : UNASSIGNED 3 (undefined)
0005 101 : PAGE/LINE
0006 110 :
UNASSIGNED 4 (undefined)
0007 111 : UNASSIGNED 5 (undefined)
507
PHASE
CORR
This selects whether to control the
phase correction of the LTC which
is output from the TIME CODE OUT
connector.
0000
OFF :
Phase correction control is not
performed.
0001 ON :
Phase correction control is
performed.
508
TCG CF
FLAG
This selects whether the CF flag of
the TCG is to ON.
0000
OFF : CF flag is OFF.
0001 ON : CF flag is ON.
509
DF MODE
(For AJ-SD93P)
This selects the DF or NDF mode for
CTL and TCG.
0000
DF :
The drop frame mode is used.
0001 NDF :
The non-drop frame mode is used.
Note:
DF/NDF switching is valid only when
the CONTROL switch is set to LOCAL
or the setup menu No. 001 (LOCAL
ENA) is set to ENA.
No./Item Description
500
VITC BLANK
For selecting whether to output the
VITC signal at the positions selected by
setup menu items No. 501 (VITC POS-1)
and No. 502 (VITC POS-2).
0000 BLANK :
VITC signals are not output.
0001
THRU :
VITC signals are output.
501
VITC POS-1
This sets the position where the
VITC signal is to be inserted.
Notes:
•
The same line as the one used for the
setup menu items No. 502 (VITC POS-
2) and No. 662 (UMID POS) setting
cannot be set.
• The default settings are not restored
even if the RESET button is pressed
while holding down the SEARCH
button.
(For AJ-SD93E)
0000 7L
::
0004
11L
::
0015 22L
(For AJ-SD93P)
0000 10L
::
0006
16L
::
0010 20L
502
VITC POS-2
This sets the position where the
VITC signal is to be inserted.
Notes:
•
The same line as the one used for the
setup menu items No. 501 (VITC POS-
1) and No. 662 (UMID POS) setting
cannot be set.
• The default settings are not restored
even if the RESET button is pressed
while holding down the SEARCH
button.
(For AJ-SD93E)
0000 7L
::
0006
13L
::
0015 22L
(For AJ-SD93P)
0000 10L
::
0008
18L
::
0010 20L
503
TCG REGEN
This selects the signal to be
regenerated when the time code
generator (TCG) in the REGEN
mode.
0000
TC&UB :
Both the time code and user bit are
regenerated.
0001 TC :
Only the time code is regenerated.
0002 UB :
Only the user bit is regenerated.
505
EXT TC SEL
This selects the time code to be
used when an external time code is
to be used.
0000
LTC :
The LTC of the TIME CODE IN
connector is used.
0001 VITC :
The VITC of the input video signal
or the timecode of the IEEE 1394
digital input signal is used.
Note:
Operation uses the VITC setting if AJ-
YA93P is not installed.
YA93P
YA93P
This appears only when the optional board
AJ-YA93P has been installed.
YA93P
