R607 ERJ3GEYJ333V Chip, 33kΩ 1/16W
R608 ERJ3GEYJ822V Chip, 8.2kΩ 1/16W
R610 ERJ3GEYJ473V Chip, 47kΩ 1/16W
R612 ERJ3GEYJ473V Chip, 47kΩ 1/16W
R613 ERJ3GEYJ103V Chip, 10kΩ 1/16W
R614 ERJ3GEYJ103V Chip, 10kΩ 1/16W
R615 ERJ6GEYJ103 Chip, 10kΩ 1/10W
R616 ERJ3GEYJ684V Chip, 680kΩ 1/16W
R617 ERJ3GEYJ103V Chip, 10kΩ 1/16W
R618 ERJ3GEYJ223V Chip, 22kΩ 1/16W
R619 ERJ3GEYJ473V Chip, 47kΩ 1/16W
R620 ERJ3GEYJ103V Chip, 10kΩ 1/16W
R621 ERJ3GEYJ472V Chip, 4.7kΩ 1/16W
R622 ERJ6GEYJ473 Chip, 47kΩ 1/10W
R624 ERJ3GEYJ104V Chip, 100kΩ 1/16W
R625 ERJ3GEYJ473V Chip, 47kΩ 1/16W
R626 ERJ6GEYJ102 Chip, 1kΩ 1/10W
R627 ERJ3GEYJ103V Chip, 10kΩ 1/16W
R628 ERJ3GEYJ103V Chip, 10kΩ 1/16W
R629 ERJ8GEYJ104V Chip, 100kΩ 1/8W
R631 ERJ6GEYJ821 Chip, 820Ω 1/10W
R632 ERJ6GEYJ473 Chip, 47kΩ 1/10W
R634 ERJ6GEYJ561 Chip, 560Ω 1/10W
R638 ERJ3GEYJ102V Chip, 1kΩ 1/16W
R639 ERJ3GEYJ102V Chip, 1kΩ 1/16W
R640 ERJ6GEYJ561 Chip, 560Ω 1/10W
R641 ERJ3GEYJ102V Chip, 1kΩ 1/16W
R646 ERJ3GEYJ104V Chip, 100kΩ 1/16W
R653 ERJ3GEYJ512V Chip, 5.1kΩ 1/16W
R654 ERJ6GEYJ512V Chip, 5.1kΩ 1/10W
R655 ERJ6GEYJ103 Chip, 10kΩ 1/10W
R656 ERJ6GEYJ272 Chip, 2.7kΩ 1/10W
R657 ERJ3GEYJ272V Chip, 2.7kΩ 1/16W
R658 ERJ6GEYJ473 Chip, 47kΩ
1/10W
R659 ERJ6GEYJ272 Chip, 2.7kΩ 1/10W
R660 ERJ6GEYJ272 Chip, 2.7kΩ 1/10W
R661 ERJ6GEYJ473 Chip, 47kΩ 1/10W
R662 ERJ3GEYJ472V Chip, 4.7kΩ 1/16W
R663 ERJ6GEYJ512V Chip, 5.1kΩ 1/10W
R664 ERJ6GEYJ512V Chip, 5.1kΩ 1/10W
R670 ERJ3GEYJ104V Chip, 100kΩ 1/16W
R671 ERJ3GEYJ104V Chip, 100kΩ 1/16W
R673 ERJ3GEYJ104V Chip, 100kΩ 1/16W
R674 ERJ3GEYJ272V Chip, 2.7kΩ 1/16W
R675 ERJ6GEYJ272 Chip, 2.7kΩ 1/10W
R676 ERJ3GEYJ472V Chip, 4.7kΩ 1/16W
R677 ERJ6GEYJ561 Chip, 560Ω 1/10W
R678 ERJ3GEYJ104V Chip, 100kΩ 1/16W
R680 ERJ6GEYJ271 Chip, 270Ω 1/10W
R681 ERJ6GEYJ562 Chip, 5.6kΩ 1/10W
R682 ERJ3GEYJ473V Chip, 47kΩ 1/16W
R683 ERJ3GEYJ471V Chip, 470Ω 1/16W
R684 ERJ6GEYJ561 Chip, 560Ω 1/10W
R685 ERJ3GEYJ561V Chip, 560Ω 1/16W
R686 ERJ3GEYJ561V Chip, 560Ω 1/16W
R687 ERJ6GEYJ561 Chip, 560Ω 1/10W
R688 ERJ6GEYJ561 Chip, 560Ω 1/10W
R689 ERJ3GEYJ561V Chip, 560Ω 1/16W
R690 ERJ3GEYJ561V Chip, 560Ω 1/16W
R701 ERJ6GEYJ102 Chip, 1kΩ 1/10W
R702 ERJ3GEYJ224V Chip, 220kΩ 1/16W
R703 ERJ6GEYJ473 Chip, 47kΩ 1/10W
R704 ERJ8GEYJ4R7V Chip, 4.7Ω 1/8W
R705 ERJ6GEYJ682 Chip, 6.8kΩ 1/10W
R715 ERJ3GEYJ472V Chip, 4.7kΩ 1/16W
R716 ERJ6GEYJ473 Chip, 47kΩ 1/10W
R717 ERJ3GEYJ433V Chip, 43kΩ 1/16W
R719 ERJ3GEYJ684V Chip, 680k
Ω 1/16W
R722 ERJ3GEYJ104V Chip, 100kΩ 1/16W
R732 ERJ6ENF1802V Chip, 18kΩ 1/10W
R733 ERJ6ENF1303V Chip, 130kΩ 1/10W
R734 ERJ6ENF2201V Chip, 2.2kΩ 1/10W
R755 ERJ6GEYJ102 Chip, 1kΩ 1/10W
R760 ERJ6GEYJ152 Chip, 1.5kΩ 1/10W
Ref. No. Part No. Part Name & Description Remarks
R761 ERDS1FJ3R9 Carbon, 3.9Ω 1/2W
R770 ERJ6GEY0R00V Chip, 0Ω 1/10W
R779 ERJ8GX0R00V Chip, 0Ω 1/8W
R790 ERJ3GEYJ223V Chip, 22kΩ 1/16W
R791 ERJ6GEYJ223 Chip, 22kΩ 1/10W
R794 ERJ3GEYJ102V Chip, 1kΩ 1/16W
R795 ERJ6ENF1002 Chip, 10kΩ 1/10W
R796 ERJ6ENF2703V Chip, 270kΩ 1/10W
R797 ERJ6ENF2001V Chip, 2kΩ 1/10W
CONNECTORs
CN202 K2KF29Z00038 Plug, 4P
CN255 K2KF29Z00035 Plug, 4P
CN302 K2KF29Z00037 Plug, 4P
CN351 K2KF29Z00033 Plug, 4P
CN601 K1MN16BA0111 Connector, 16P
CN651 K1KA18A00074 Connector, 18P
CN670 K1PQ07A00005 Connector, 7P
CN680 K1AA113B0002 Connector, 13P
CN701 K1FA116B0028 Connector, 16P
CN760 K1KA02AA0229 Connector, 2P
COILs
L50 G1C150K00011 Coil
L52 G1CR56JA0036 Coil
L53 G1C101JA0036 Coil
L401 G1C101JA0036 Coil
L501 G1C330JA0036 Coil
L504 G1C330JA0036 Coil
L601 G1C330JA0036 Coil
L602 G1C101JA0036 Coil
L603 G1C330JA0036 Coil
L630 G0C330K00004 RF Coil
L701 YELTBL01R1AT Coil
L702 G0A151J00006 Coil
SWITCHes
SW601 K0L1BA000099 Switch
SW602 K0L1BA000104 Switch
CRYSTALs
XL401 H0D720400006 Crystal Oscillator
XL501 H0D433400003 Crystal Oscillator
XL601 H0D368400015 Crystal Oscillator
XL602 H0J327200161 Crystal Oscillator
NETWORK RESISTORs
R606 EXBV8V102JV Network Resistor
FILTERs
Z50 J0LM00000001 Noise Filter
THERMISTORs
PT701 YERT7AR4R7MT Thermistor
[E9782] Display Block
IC's AND TRANSISTORs
IC900 C2CBYY000150 IC
IC901 C3FBMD000236 IC
IC902 C0EBF0000374 IC
Q902 DTA144EKAT46 Transistor
Q903 B1GBCFNN0004 Transistor
Q912 B1BBAC000014 Transistor
Q941 B1ABCF000187 Transistor
Q942 B1ABCF000187 Transistor
Q943 B1ABCF000187 Transistor
Ref. No. Part No. Part Name & Description Remarks
