Panasonic CQ-C7703N

Pin
No.
Port Descriptions I/O (V)
1 AVSS GND - 0
2 LD-MT Loading Motor drive IC
control 1
O 3.2
3 CNT Loading Motor drive IC
control 2
O 3.2
4 - Not Connected - -
5 LD-EJ Loading Motor drive IC
control (Eject)
O 0
6 AMUTE Mute signal output O 0
7 - Not Connected - -
8 SBSY DSP IC SBSY O 0
9 - Not Connected - -
10 - Not Connected - -
11 TXD0 Serial data output O 0
12 RXD0 Serial data input I 0
13 CLK0 Clock input I 2.9
14 TXD1 Serial data output O 3.2
15 RXD1 Serial data input I 0
