Panasonic CQ-C8405N

IC201:BA5834FM-E2
Pin
No.
Port Description I/O Play
(V)
Stop
(V)
Load
(V)
Eject
(V)
1 BIAS1 BIAS INPUT TERMINAL I 1.65 1.65 1.65 1.65
2 VIN1 CH1 INPUT TERMINAL I 1.7 1.65 1.65 1.65
3 VIN2 CH2 INPUT TERMINAL I 1.65 1.65 1.65 1.65
4 OPIN(+) OPIN INPUT TERMINAL I 1.65 1.65 1.65 1.65
5 OPIN(-) OPIN OUTPUT TERMINAL I 1.65 1.65 1.65 1.65
6 OPOUT OPOUT I 1.65 1.65 1.65 1.65
7 GND GND 0 0 0 0
8 PowVcc1 ”Vcc(CH1,CH2) _ 8 8 8
9 MUTE12 ”CH1CH2, _ 3.3 3.3 3.3 0
10 GND GND _ 0 0 0 0
11 VO2(-) DRIVER CH2(-) OUTPUT O 4.6 4.6 4.6 4.6
12 VO2(+) DRIVER CH2(+) OUTPUT O 4.6 4.6 4.6 4.6
13 VO1(-) DRIVER CH1(-) OUTPUT O 4.4 4.6 4.6 4.6
14 VO1(+) DRIVER CH1(+) OUTPUT O 4.8 4.6 4.6 4.6
15 VO4(+) DRIVER CH4(+) OUTPUT O 3.9 3.9 0.2 7.4
16 VO4(-) DRIVER CH4(-) OUTPUT O 3.9 3.9 7.4 0.2
17 VO3(+) DRIVER CH3(+) OUTPUT O 4.2 3.9 3.9 3.9
18 VO3(-) DRIVER CH3(-) OUTPUT O 3.6 3.9 3.9 3.9
19 GND GND 0 0 0 0
20 MUTE4 CH4 MUTE OUTPUT O 0 0 3.3 3.3
21 PowVcc2 Vcc(CH3,CH4) 8 8 8
22 PreVcc PreVcc _ 8 8 8 8
23 VIN3 CH3 INPUT TERMINAL I 1.65 1.65 1.65 1.65
24 LDIN CH4 LODING INPUT
TERMINAL
I 3.2 3.2 0 3.2
25 BIAS2 BIAS 2 INPUT TERMINAL I 1.1 1.1 1.1 1.1
26 TRIN CH4 DRIVER INPUT
TERMINAL
I 1.65 1.65 1.65 1.65
27 MUTE3 CH3 MUTE TERMINAL _ 3.3 3.3 0 0
28 CNT CONTROL TERMINAL _ 3.2 3.2 0 0
15
CQ-C8405N
