Panasonic CQ-C8405N

13 REPLACEMENT PARTS
LIST
Notes :
1. Be sure to make your orders of replacement parts
according to this list.
2. Important safety notice: Components, identified by
mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3. Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4. The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
•
• •
• Order intake period is basically six months after the first
shipment.
5. “T”marks in remarks colum are indicated supply parts of
PTW.
Ref.
No.
Part No. Part Name & Description Remarks
[E-4C308] Main/Sub Block
IC’s AND TRANSISTORs
IC201 C1BB00000796 IC T
IC221 C1BB00001131 IC T
IC231 C0JBZS000003 IC T
IC251 C0ABBA000221 IC T
IC252 C0ABCA000121 IC T
IC271 C1ZAZ0001486 IC T
IC401 C1BB00001045 IC T
IC501 C1BB00000960 IC T
IC601 YEAMB90F439P IC T
IC650 C0JBAA000372 IC T
IC670 C0JBAZ000904 IC T
IC701 C0DAZHF00004 IC T
IC702 C0EBZ0000035 IC T
IC730 C0DAEKG00002 IC T
IC752 C0CBCBG00012 IC T
IC755 C0DBZGD00040 IC T
IC760 C0GBG0000032 IC T
IC770 C0DBAHG00020 IC T
IC790 C0CBCYG00004 IC T
PA51 C5BA00000123 Tuner T
Q55 B1GDGFEH0001 Transistor T
Q56 B1AAEC000002 Transistor T
Q66 B1ABCF000187 Transistor T
Q220 B1GBCFNN0004 Transistor T
Q235 B1GBHBEA0004 Transistor T
Q241 B1GBHBEA0004 Transistor T
Q251 B1GBHBEA0004 Transistor T
Q252 B1GBHBEA0004 Transistor T
Q320 B1GBCFNN0004 Transistor T
Q335 B1GBHBEA0004 Transistor T
Q341 B1GBHBEA0004 Transistor T
Q351 B1GBHBEA0004 Transistor T
Q352 B1GBHBEA0004 Transistor T
Q353 B1GBHBEA0004 Transistor T
Q354 B1GDCFJJ0002 Transistor T
Q371 B1GBCFNN0004 Transistor T
Q411 B1CBGF000005 Transistor T
Ref.
No.
Part No. Part Name & Description Remarks
Q630 B1GBCFNN0004 Transistor T
Q633 B1GDCFJJ0002 Transistor T
Q650 B1GBCFJN0004 Transistor T
Q651 B1GBCFJN0004 Transistor T
Q652 B1GBCFJN0004 Transistor T
Q680 B1GDGFEH0001 Transistor T
Q681 B1GDCFJJ0002 Transistor T
Q701 B1BACF000026 Transistor T
Q760 B1GBCFNN0004 Transistor T
Q771 B1ABCF000187 Transistor T
Q772 B1GBCFJN0004 Transistor T
Q791 B1GBNCEJ0003 Transistor T
Q793 B1GBCFJN0004 Transistor T
DIODEs
D201 B0ECKP000002 Silcon Diode T
D202 B0ECKP000002 Silcon Diode T
D203 B0ECKP000002 Silcon Diode T
D204 B0ECKP000002 Silcon Diode T
D251 B0JCMC000004 Diode T
D301 B0ECKP000002 Silcon Diode T
D302 B0ECKP000002 Silcon Diode T
D303 B0ECKP000002 Silcon Diode T
D304 B0ECKP000002 Silcon Diode T
D504 B0BC5R000020 Zener Diode T
D601 B0JCMC000004 Diode T
D630 B3AAB0000143 CHIP LED T
D631 B0BC5R600010 Zener Diode T
D632 MA3X152D0L Diode T
D635 B0BC5R600010 Zener Diode T
D636 B0BC5R600010 Zener Diode T
D637 B0BC5R600010 Zener Diode T
D638 B0BC5R600010 Zener Diode T
D639 B0BC5R600010 Zener Diode T
D670 B0JCMC000004 Diode T
D680 MA3X152A0L Diode T
D701 B0BA04700003 Diode T
D702 MA2Q73600L Diode T
D703 B0BC5R7A0062 Zener Diode T
D704 B0JCMC000004 Diode T
D705 B0ECKP000002 Silcon Diode T
D706 B0ECKP000002 Silcon Diode T
D707 B0JCPE000004 Diode T
D708 MA2Q73600L Diode T
D710 B0JCMC000004 Diode T
D715 MA3X152A0L Diode T
D716 MA3X72100L Diode T
D751 B0ECKP000002 Silcon Diode T
D752 B0ECKP000002 Silcon Diode T
D760 B0BC5R000020 Zener Diode T
D761 B0BC3R0A0058 Zener Diode T
D770 B0JCMC000004 Diode T
D771 B0JCQD000002 Diode T
D772 B0BC013A0063 Diode T
CAPACITORs
C52 F1J1H470A732 Ceramic 47pF 50WV T
C53 F1J1H103A733 Ceramic 0.01MFD 50WV T
C54 F2A1A221A023 Electrolytic 220pF 10WV T
C55 F1J1H103A733 Ceramic 0.01MFD 50WV T
C56 F3F1E105A001 Ceramic 1MFD 25WV T
C57 F2A1A101A023 Electrolytic 100pF 10WV T
C58 F1J1C104A148 Ceramic 0.1MFD 16WV T
C61 F1J1H183A733 Ceramic 0.018MFD 50WV T
C62 F1J1H183A733 Ceramic 0.018MFD 50WV T
C65 F1J1H102A733 Ceramic 1000pF 50WV T
C66 F1J1H471A732 Ceramic 470pF 50WV T
C206 F2A1C100A029 Electrolytic 10pF 16WV T
C213 F1J1A225A063 Ceramic 2.2MFD 10WV T
C215 F1J1A225A063 Ceramic 2.2MFD 10WV T
C217 F1J1C334A006 Ceramic 0.33MFD 16WV T
