Panasonic CQ-RD153N

Ref.
No.
Part No. Part Name & Description Remarks
C123 ECEA1CKS100IV Electrolytic 10MFD 16WV T
C124 ECEA1HKS3R3IV Electrolytic 3.3MFD 50WV T
C128 ECUV1H333KBN Ceramic 0.033MFD 50WV T
C129 ECUV1H333KBN Ceramic 0.033MFD 50WV T
C130 ECUV1H562KBN Ceramic 5600pF 50WV T
C131 ECUV1H562KBN Ceramic 5600pF 50WV T
C132 ECEA1AKS221IV Electrolytic 220MFD 10WV T
C133 ECUV1H103KBN Ceramic 0.01MFD 50WV T
C135 ECEA1HKS3R3IV Electrolytic 3.3MFD 50WV T
C136 ECEA1HKS3R3IV Electrolytic 3.3MFD 50WV T
C137 ECEA1HKS3R3IV Electrolytic 3.3MFD 50WV T
C138 ECEA1HKS3R3IV Electrolytic 3.3MFD 50WV T
C201 ECUV1H122KBN Ceramic 0.0012MFD 50WV T
C202 ECEA1AKS101IV Electrolytic 100MFD 10WV T
C203 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C204 ECUV1H273KBN Ceramic 0.027MFD 50WV T
C205 ECUV1H270JCN Ceramic 27PF 50WV T
C206 ECUV1H270JCN Ceramic 27PF 50WV T
C207 ECUV1H103KBN Ceramic 0.01MFD 50WV T
C208 ECEA1AKS470IV Electrolytic 47MFD 10WV T
C209 ECUV1H271JCN Ceramic 270pF 50WV T
C210 ECUV1H104KBN Ceramic 0.1MFD 50WV T
C211 ECEA1CKS100IV Electrolytic 10MFD 16WV T
C241 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C242 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C249 ECUV1H222KBN Ceramic 2200pF 50WV T
C250 ECUV1H222KBN Ceramic 2200pF 50WV T
C251 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C252 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C259 ECUV1H103KBN Ceramic 0.01MFD 50WV T
C280 ECUV1H471KBN Ceramic 470PF 50WV T
C301 ECUV1H122KBN Ceramic 0.0012MFD 50WV T
C302 ECEA1AKS101IV Electrolytic 100MFD 10WV T
C303 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C304 ECUV1H273KBN Ceramic 0.027MFD 50WV T
C307 ECEA1AKS221IV Electrolytic 220MFD 10WV T
C341 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C342 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C349 ECUV1H222KBN Ceramic 2200pF 50WV T
C350 ECUV1H222KBN Ceramic 2200pF 50WV T
C351 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C352 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C406 ECUV1H150JCN Ceramic 15pF 50WV T
C407 ECUV1H150JCN Ceramic 15pF 50WV T
C408 ECUV1H104KBN Ceramic 0.1MFD 50WV T
C410 ECEA0JKS331IV Electrolytic 330MFD 6.3WV T
C411 YEECFYH0H223 Electrolytic 22000MFD 5.5WV T
C600 ECUV1H104KBN Ceramic 0.1MFD 50WV T
C607 ECUV1H104KBN Ceramic 0.1MFD 50WV T
C610 ECEA1CKS100IV Electrolytic 10MFD 16WV T
C630 ECEA1CKS470IV Electrolytic 47MFD 16WV T
C631 ECEA1HKS100IV Electrolytic 10MFD 50WV T
C655 ECUV1H224ZFN Ceramic 0.22MFD 50WV T
C701 ECA1CM222B Electrolytic 0.0022MFD 16WV T
C707 ECEA1CU102YB Electrolytic 1000MFD 16WV T
C708 ECEA1AU221I Electrolytic 220MFD 10WV T
C710 ECEA1AKS221IV Electrolytic 220MFD 10WV T
C715 ECA1CHG101I Electrolytic 100MFD 16WV T
C717 ECEA1CKS100IV Electrolytic 10MFD 16WV T
C718 ECUV1H224ZFN Ceramic 0.22MFD 50WV T
C720 ECA1CDT332Y Ceramic 0.0033MFD 16WV T
C721 ECEA1HKS2R2IV Electrolytic 2.2MFD 50WV
C722 ECEA1HKS010IV Electrolytic 1MFD 50WV T
C727 ECEA1CKS470IV Electrolytic 47MFD 16WV T
C732 ECUV1H104KBN Ceramic 0.1MFD 50WV T
C751 ECEA1CKS100IV Electrolytic 10MFD 16WV T
DISPLAY BLOCK [E-4C245]
C901 ECUV1H104KBN Ceramic 0.1MFD 50WV T
C902 ECUV1H104KBN Ceramic 0.1MFD 50WV T
C903 ECUV1H561KBN Ceramic 560PF 50WV T
C904 ECUV1H104KBN Ceramic 0.1MFD 50WV T
Ref.
No.
Part No. Part Name & Description Remarks
4. Resistors
MAIN BLOCK [E-4C244]
J1 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J2 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J3 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J4 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J5 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J6 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J7 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J8 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J9 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J10 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J11 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J12 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J18 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J23 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J24 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J25 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J26 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J27 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J28 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J29 ERJ6GEY0R00V Chip 0 ohms 1/10W T
J100 ERJ8GX0R00V Chip 0 ohms 1/8W T
J101 ERJ8GX0R00V Chip 0 ohms 1/8W T
J102 ERJ8GX0R00V Chip 0 ohms 1/8W T
J106 ERJ8GX0R00V Chip 0 ohms 1/8W T
J105 ERJ8GX0R00V Chip 0 ohms 1/8W T
R055 ERDS2TJ102T Carbon 1k ohms 1/4W T
R101 ERJ8GEYJ5R6V Carbon 5.6 ohms 1/8W T
R103 ERDS2TJ101T Carbon 100 ohms 1/4W T
R104 ERJ6GEYJ681V Carbon 680 ohms 1/10W T
R105 ERJ6GEYJ153V Chip 15k ohms 1/10W T
R106 ERJ6GEYJ152V Chip 1.5k ohms 1/10W T
R107 ERJ6GEYJ222V Chip 2.2k ohms 1/10W T
R108 ERJ6GEYJ473V Chip 47k ohms 1/10W T
R110 ERJ6GEYJ221V Carbon 220 ohms 1/10W T
R113 ERD25TJ103T Carbon 10k ohms 1/4W T
R114 ERD25TJ103T Carbon 10k ohms 1/4W T
R146 ERJ8GEYJ223V Chip 22k ohms 1/8W T
R151 ERJ6GEYJ182V Chip 1.8k ohms 1/10W T
R201 ERJ6GEYJ333V Chip 33k ohms 1/10W T
R202 ERJ6GEYJ330V Carbon 33 ohms 1/10W T
R203 ERJ6GEYJ472V Chip 4.7k ohms 1/10W T
R204 ERJ6GEYJ124V Carbon 120k ohms 1/10W T
R205 ERJ6GEYJ224V Chip 220k ohms 1/10W T
R225 ERJ6GEYJ822V Chip 8.2k ohms 1/10W T
R226 ERJ6GEYJ332V Chip 3.3k ohms 1/10W T
R241 ERJ6GEYJ103V Chip 10k ohms 1/10W T
R242 ERJ6GEYJ103V Chip 10k ohms 1/10W T
R243 ERJ6GEYJ471V Chip 470 ohms 1/10W T
R263 ERD25TJ101T Carbon 100 ohms 1/4W T
R264 ERD25TJ101T Carbon 100 ohms 1/4W T
R281 ERJ6GEYJ223V Chip 22k ohms 1/10W T
R282 ERJ6GEYJ223V Chip 22k ohms 1/10W T
R301 ERJ6GEYJ333V Chip 33k ohms 1/10W T
R302 ERJ6GEYJ330V Carbon 33 ohms 1/10W T
R303 ERJ6GEYJ472V Chip 4.7k ohms 1/10W T
R304 ERJ6GEYJ124V Carbon 120k ohms 1/10W T
R309 ERDS2TJ221T Carbon 220 ohms 1/4W T
R325 ERJ6GEYJ822V Chip 8.2k ohms 1/10W T
R326 ERJ6GEYJ332V Chip 3.3k ohms 1/10W T
R338 ERDS2TJ102T Carbon 1k ohms 1/4W T
R339 ERDS2TJ102T Carbon 1k ohms 1/4W T
R341 ERJ6GEYJ103V Chip 10k ohms 1/10W T
R341 ERJ6GEYJ103V Chip 10k ohms 1/10W T
R342 ERJ6GEYJ103V Chip 10k ohms 1/10W T
R343 ERJ6GEYJ471V Chip 470 ohms 1/10W T
R351 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R363 ERD25TJ101T Carbon 100 ohms 1/4W T
R364 ERD25TJ101T Carbon 100 ohms 1/4W T
R381 ERJ6GEYJ223V Chip 22k ohms 1/10W T
15
CQ-RD153N
