Panasonic CQ-RDP102N

Ref.
No.
Part No. Part Name & Description Remarks
L400 YELT02C101KT Coil
L701 YERST0001 Coil
L901 YELT02C101KT Coil
CRYSTALs
XL400 H0D103500001 Crystal
XL600 YERCF0002 Crystal
XL601 YERXL0001 Crystal
XL901 YEXL49U0433T Crystal
THERMISTOR
PT701 YERT7AR4R7MT Thermister
[E9009A] Display Block
IC´s and TRANSISTORs
IC901 YEAMLC75854T IC
IC902 YEAMSBX8035F IC
Q901 B1GDCFJJ0023 Transistor
DIODEs
D901 MA8056L Diode
D902 MA8056L Diode
D903 MA8056L Diode
D904 MA8056L Diode
D905 MA8056L Diode
D906 B3AAB0000080 Diode
D925 LN1461CTR Diode A,C
D925 LN1361C6TR Diode B,E
D925 LN1261CTR Diode D
D926 LN1461CTR Diode A,C
D926 LN1361C6TR Diode B,E
D926 LN1261CTR Diode D
D927 LN1461CTR Diode A,C
D927 LN1361C6TR Diode B,E
D927 LN1261CTR Diode D
D929 LN1461CTR Diode A,C
D929 LN1361C6TR Diode B,E
D929 LN1261CTR Diode D
D930 LN1461CTR Diode A,C
D930 LN1361C6TR Diode B,E
D930 LN1261CTR Diode D
D931 LN1461CTR Diode A,C
D931 LN1361C6TR Diode B,E
D931 LN1261CTR Diode D
D932 LN1461CTR Diode A,C
D932 LN1361C6TR Diode B,E
D932 LN1261CTR Diode D
D933 LN1461CTR Diode A,C
D933 LN1361C6TR Diode B,E
D933 LN1261CTR Diode D
CAPACITORs
C901 YECUS1E104ZF Ceramic, 0.1µF 25WV
C902 YECUS1E104ZF Ceramic, 0.1µF 25WV
C903 YECUS1H681JC Ceramic, 680PF 50WV
C904 YECUS1E104ZF Ceramic, 0.1µF 25WV
C905 YECUS1E104ZF Ceramic, 0.1µF 25WV
C906 YECUS1H102KX Ceramic, 1000PF 50WV
C912 YECUS1E104ZF Ceramic, 0.1µF 25WV
RESISTORs
R901 ERJ6GEYJ4R7 Chip, 4.7
Ω
ΩΩ
Ω
1/10W
R902 ERJ6GEYJ102 Chip, 1k
Ω
ΩΩ
Ω
1/10W
R903 ERJ6GEYJ102 Chip, 1k
Ω
ΩΩ
Ω
1/10W
R904 ERJ6GEYJ102 Chip, 1k
Ω
ΩΩ
Ω
1/10W
R905 ERJ6GEYJ102 Chip, 1k
Ω
ΩΩ
Ω
1/10W
Ref.
No.
Part No. Part Name & Description Remarks
R906 ERJ6GEYJ102 Chip, 1k
Ω
ΩΩ
Ω
1/10W
R908 ERJ6GEYJ332 Chip, 3.3k
Ω
ΩΩ
Ω
1/10W
R909 ERJ6GEYJ4R7 Chip, 4.7
Ω
ΩΩ
Ω
1/10W
R910 ERJ6GEYJ473 Chip, 47k
Ω
ΩΩ
Ω
1/10W
R911 ERJ6GEYJ103 Chip, 10k
Ω
ΩΩ
Ω
1/10W
R912 ERJ6GEYJ102 Chip, 1k
Ω
ΩΩ
Ω
1/10W
R921 ERJ6GEYJ221 Chip, 220
Ω
ΩΩ
Ω
1/10W
R922 ERJ6GEYJ331 Chip, 330
Ω
ΩΩ
Ω
1/10W
R923 ERJ6GEYJ221 Chip, 220
Ω
ΩΩ
Ω
1/10W
R929 ERJ6GEYJ221 Chip, 220
Ω
ΩΩ
Ω
1/10W
R930 ERJ6GEYJ331 Chip, 330
Ω
ΩΩ
Ω
1/10W
R931 ERJ6GEYJ221 Chip, 220
Ω
ΩΩ
Ω
1/10W
CONNECTORs
CJ640 YEAE012476 Connector, 12P
SWITCHEs
SW902 YEAS09312 Switch
SW903 K0H1BA000339 Switch
SW904 K0H1BA000339 Switch
SW906 K0H1BA000339 Switch
SW908 YEAS09312 Switch
SW909 YEAS09312 Switch
SW910 YEAS09312 Switch
SW912 K0H1BA000339 Switch
SW913 K0H1BA000339 Switch
SW914 K0H1BA000339 Switch
SW915 YEAS09312 Switch
SW916 YEAS09312 Switch
SW917 YEAS09312 Switch
SW918 YEAS09312 Switch
SW919 YEAS09312 Switch
SW920 YEAS09312 Switch
SW921 K0H1BA000339 Switch
SW922 K0H1BA000339 Switch
SW926 YEAS09312 Switch
LCD
LCD901 L5ACAJB00001 LCD
LAMPs
PL921 YEALHSLO004 Pilot Lamp A,C
PL921 YEALHSLG003 Pilot Lamp B,E
PL921 YEALHSLR014 Pilot Lamp D
PL922 YEALHSLO004 Pilot Lamp A,C
PL922 YEALHSLG003 Pilot Lamp B,E
PL922 YEALHSLR014 Pilot Lamp D
[E9136] CD Servo Block
IC´s and TRANSISTORs
IC1 C1BB00000665 IC
IC2 C0GBY0000020 IC
Q1 B1BDBC000001 Transistor
DIODEs
D1 B0ACCK000005 Diode
CAPACITORs
C3 F1H1H8R0A226 Ceramic, 8PF 50WV
C4 YECUZ1H270JC Ceramic, 27PF 50WV
C5 F1H1H4R00010 Ceramic, 4.0PF 50WV
C6 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C7 YECUZ1E104ZF Ceramic, 0.1µF 25WV
C8 YECUZ1H472KX Ceramic, 4700PF 50WV
C9 YECUZ1E104ZF Ceramic, 0.1µF 25WV
12
CQ-RDP162N / CQ-RDP112N / CQ-RDP152N / CQ-RDP142N / CQ-RDP102N
