10.2. Replacement Parts List [CQ-RX200U]
Notes :
1. Be sure to make your orders of replacement parts accord-
ing to this list.
2. Important safety notice: Components, identified by
mark have special characteristics important for safety.
When replacing any of these components, use only man-
ufacturer's specified parts.
3. Location keys in the remarks column indicates the gen-
eral location of the parts shown in the exploded drawing,
as in a road map.
4. The marking (RTL) indicates that Retention Time is lim-
ited for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability
is dependent on the type of assembly, and in accordance
with the laws governing part and product retention. After
the end of this period, the assembly will no longer be
available.
• Order intake period is basically six months after the first
shipment.
5. Reference materials of parts with the “TSN“ mark in the
remarks column are uploaded in the TSN (Technical Ser-
vice Navigation) system website. Please download from
that website for references.
Ref. No. Part No. Part Name & Description Remarks
[7231-02-11] Main Block
IC's and TRANSISTORs
IC201 YESAM440 IC
IC271 C1EA00000041 IC
IC601 YESAM434 IC
IC602 YESAM436 IC
IC671 YESAM391 IC
IC701 YESAM441 IC
IC751 YESAM424 IC
IC791 YESAM344 IC
IC801 YESAM428 IC
IC851 YESAM437 IC
IC852 YESAM439 IC
PA051 YESAP387 Tuner Pack
Q052 YESAN154 Transistor
Q055 YESAN154 Transistor
Q251 YESAN153 Transistor
Q261 YESAN153 Transistor
Q266 YESAN155 Transistor
Q366 YESAN155 Transistor
Q401 B1CBGF000005 FET
Q601 YESAN152 Transistor
Q602 YESAN152 Transistor
Q751 YESAN157 Transistor
Q752 YESAN079 Transistor
Q770 YESAN149 Transistor
Q871 YESAN156 Transistor
DIODEs
D003 YESAD155 Diode
D050 YESAD155 Diode
D053 YESAD188 Zener Diode
D201 YESAD167 Diode
D251 YESAD191 Zener Diode
D270 YESAD192 Diode
D271 YESAD192 Diode
D272 YESAD192 Diode
D273 YESAD192 Diode
D274 YESAD192 Diode
D275 YESAD192 Diode
D276 YESAD192 Diode
D277 YESAD192 Diode
D351 YESAD191 Zener Diode
D401 YESAD144 Diode
D601 YESAD143 Diode
D672 YESAD188 Zener Diode
D675 YESAD144 Diode
D682 YESAD133 Zener Diode
D683 YESAD133 Zener Diode
D701 YESAD193 Diode
D703 YESAD196 Diode
D704 YESAD198 Diode
D751 YESAD197 Diode
D752 YESAD192 Diode
D791 YESAD192 Diode
D971 YESAD150 Zener Diode
D974 YESAD189 Zener Diode
D981 YESAD149 Diode
D991 YESAD155 Diode
CAPACITORs
C051 YESCC667 Ceramic, 47pF 50WV
C053 YESCC651 Ceramic, 0.01µF 50WV
C055 YESCC651 Ceramic, 0.01µF 50WV
C061 YESCC658 Ceramic, 0.027µF 25WV
C062 YESCC658 Ceramic, 0.027µF 25WV
C065 YESCC650 Ceramic, 1000pF 50WV
C067 YESCC651 Ceramic, 0.01µF 50WV
C068 YESCC599 Electrolytic, 220µF 10WV
C201 YESCC675 Electrolytic, 0.33µF 50WV
C202 YESCC550 Electrolytic, 3.3µF 50WV
C203 YESCC550 Electrolytic, 3.3µF 50WV
C204 YESCC550 Electrolytic, 3.3µF 50WV
C205 YESCC546 Electrolytic, 10µF 16WV
C206 YESCC652 Ceramic, 0.1µF 16WV
C207 YESCC652 Ceramic, 0.1µF 16WV
C208 YESCC653 Ceramic, 1500pF 50WV
C210 YESCC662 Ceramic, 680pF 50WV
C240 YESCC659 Ceramic, 330pF 50WV
C241 YESCC659 Ceramic, 330pF 50WV
C242 YESCC659 Ceramic, 330pF 50WV
C243 YESCC659 Ceramic, 330pF 50WV
C244 YESCC659 Ceramic, 330pF 50WV
C245 YESCC659 Ceramic, 330pF 50WV
C246 YESCC659 Ceramic, 330pF 50WV
C247 YESCC659 Ceramic, 330pF 50WV
C252 YESCC660 Ceramic, 4700pF 50WV
C255 YESCC549 Electrolytic, 2.2µF 50WV
C262 YESCC372 Electrolytic, 4.7µF 25WV
C263 YESCC679 Plastic, 0.22µF 50WV
C267 YESCC679 Plastic, 0.22µF 50WV
C271 YESCC651 Ceramic, 0.01µF 50WV
C272 YESCC651 Ceramic, 0.01µF 50WV
C273 YESCC651 Ceramic, 0.01µF 50WV
C274 YESCC651 Ceramic, 0.01µF 50WV
C276 YESCC677 Electrolytic, 22µF 16WV
C277 YESCC670 Ceramic, 1µF 6.3WV
C278 YESCC673 Ceramic, 0.22µF 50WV
C279 YESCC368 Electrolytic, 2200µF 16WV
C288 YESCC673 Ceramic, 0.22µF 50WV
C292 YESCC651 Ceramic, 0.01µF 50WV
C301 YESCC675 Electrolytic, 0.33µF 50WV
C302 YESCC550 Electrolytic, 3.3µF 50WV
C303 YESCC550 Electrolytic, 3.3µF 50WV
C304 YESCC550 Electrolytic, 3.3µF 50WV
C305 YESCC550 Electrolytic, 3.3µF 50WV
C306 YESCC652 Ceramic, 0.1µF 16WV
C307 YESCC599 Electrolytic, 220µF 10WV
C308 YESCC653 Ceramic, 1500pF 50WV
C310 YESCC662 Ceramic, 680pF 50WV
C362 YESCC372 Electrolytic, 4.7µF 25WV
