Panasonic CQC1103U - AUTO RADIO/CD DECK

Ref.
No.
Part No. Part Name & Description Remarks
DISPLAY BLOCK [E-4C291]
R901 D0GD272JA017 Chip 2.7k ohms 1/10W T
R902 D0GD683JA017 Chip 68k ohms 1/10W T
R903 D0GD102JA017 Chip 1k ohms 1/10W T
R904 D0GD102JA017 Chip 1k ohms 1/10W T
R905 D0GD102JA017 Chip 1k ohms 1/10W T
R908 D0GD681JA017 Chip 680 ohms 1/10W T
R909 D0GD102JA017 Chip 1k ohms 1/10W T
R910 D0GD4R7JA056 Chip 4.7 ohms 1/10W T
R921 D0GD561JA017 Chip 560 ohms 1/10w T
R922 D0GD561JA017 Chip 560 ohms 1/10w T
R923 D0GD561JA017 Chip 560 ohms 1/10w T
R924 D0GD821JA017 Chip 820 ohms 1/10W T
R925 D0GD241JA017 Chip 240 ohms 1/10W T
CD INTERFACE BLOCK [E-4C288]
J30 ERJ8GX0R00V Chip 0 ohms 1/8W T
J31 ERJ8GX0R00V Chip 0 ohms 1/8W T
J32 ERJ8GX0R00V Chip 0 ohms 1/8W T
J33 ERJ8GX0R00V Chip 0 ohms 1/8W T
J34 ERJ8GX0R00V Chip 0 ohms 1/8W T
J35 ERJ8GX0R00V Chip 0 ohms 1/8W T
J36 ERJ8GX0R00V Chip 0 ohms 1/8W T
J37 ERJ8GX0R00V Chip 0 ohms 1/8W T
5. Connectors
MAIN BLOCK [E-4C290]
CN601 YEAE012475A Connector T
CN602 K1KA22A00001 Connector T
CN700 K1FA116B0028 Connector T
CN900 YEAER120002 Connector T
DISPLAY BLOCK [E-4C291]
CN901 YEAE4CCN074 Connector T
CD INTERFACE BLOCK [E-4C288]
CN1 YEAE4CCN075 Connector T
CN2 YEAE4CCN057A Connector T
6. Electric Parts
SWITCHES
SW901 K0H1BA000445 Tack Swich T
SW902 K0H1BA000445 Tack Swich T
SW903 K0H1BA000445 Tack Swich T
SW904 K0H1BA000445 Tack Swich T
SW905 K0H1BA000445 Tack Swich T
SW906 K0H1BA000445 Tack Swich T
SW907 K0H1BA000445 Tack Swich T
SW908 K0H1BA000445 Tack Swich T
SW909 K0H1BA000445 Tack Swich T
SW910 K0H1BA000445 Tack Swich T
SW911 K0H1BA000445 Tack Swich T
SW912 K0H1BA000445 Tack Swich T
SW913 K0H1BA000445 Tack Swich T
SW914 K0H1BA000445 Tack Swich T
SW915 K0H1BA000445 Tack Swich T
SW919 K0H1BA000445 Tack Swich T
CRYSTAL
XL601 YEXL4C45TT2 Crystal T
COILS
L2 G0C221JA0044 Axil Coil T
L50 G0C150JA0044 Axil Coil T
L52 G0C8R2K00006 Axil Coil T
L61 NLV32TR56J Axial Coil T
Ref.
No.
Part No. Part Name & Description Remarks
L801 G1C100J00001 Coil T
L700 YETQ024C065V Choke Coil T
L901 ERJ8GX0R00V Chip 0 ohms 1/8W T
VR
VR901 EC12E24244A7 Encode T
LCD
LCD901 YEXDCM4C133 LCD T
7. Accessories
PRINT
YFM284C487CA Operating Instructions T
YFM284C488CA Operating Instructions T
YFM284C489CA Operating Instructions T
YFM284C490CA Installation Instructions T
INSTALLATION PARTS
ZZCORD-1333U Power Cord Assy(U) T
ZZBISC1101U-J Screw Kit T
FX0214C384ZA Escape Case T
8. Mechanical Parts
MISCELLANEOUS
ANT1 YAA104C700ZA ANT Jack T(3-C)
1 YFA034C053CA Upper Cover T(4-B)
2 TN-2001-1064 CD Deck T(4-C)
3 XTB26+5FFN Screw T(4-C)
4 XTW2+5FFN Screw T(4-B)
5 YFF014C055CA Heat Sink T(3-C)
6 YEJT034C019N Screw(CUP TIGHT 3X12) T(3-C)
7 XTB3+8FFZ Screw T(3-C)
8 YJS064C002FN Screw T(3-C)
9 XTB26+8GFN Screw T(3-C)
10 YFA084C063CA Rear Plate T(3-C)
11 YFC034C012CA ESC Holder T(2-C)
12 YFX054C074CA Spring (HOOK) T(2-C)
13 YEFX9991682B Release Hook T(2-C)
14 YEFS02302 Dust Felt T(2-C)
15 YEFS011113 Pad T(2-C)
16 XTN2+8GFZ Screw T(2-C)
17 YFX054C071CA Spring (PUSH BUTTON) T(2-C)
18 YFE134C491YA Button (Push) T(2-C)
19 YFC034C001CA ESC Rear Cover T(2-C)
20 YFE134C510CA Button (TUNE/TRACK)Ring T(2-B)
21 YFV024C108CA Sheet T(2-B)
22 YFE134C509CA Button (DM/REP) T(1-B)
23 YFX054C072CA Spring (OPEN) T(1-B)
24 YFE134C505CA Button(RELEASE) T(1-B)
25 YFE134C508CA Button (DISP/EJ) T(1-B)
26 YFC034C006CA ESC Front Cover T(1-B)
27 YFX014C091CA Panel Light (CD) T(1-B)
28 YFJ014C164CA ARC Panel T(1-B)
29 YFE134C513CA Button (4-6) T(1-B)
30 YFE134C514CA Button (SRC/PWR) T(1-A)
31 YFX994C126CA Two-Side Tape T(1-A)
32 YFJ014C163CA Ornament Panel(PRINT) T(1-A)
33 YFX014C090CA Back Light Assy T(2-B)
34 YFS014C110CA Rubber Gum T(2-B)
36 YFX214C405CA LCD Bracket T(2-B)
37 YFE134C506CA Button(BAND/MUTE) T(2-B)
38 YFE134C507CA Button (SQ) T(2-B)
39 ESCC1103U-TY ESC Unit Assy T(2-
B)/RTL
40 YFX054C073CA Spring (KNOB) T(1-A)
41 YFE074C068CA Vol Knob T(1-A)
42 YFE074C069CA Vol Knob Ass’y T(1-A)
43 YFE134C512CA Button (1-3) T(1-A)
44 YFC054C079YA Trim Plate T(1-A)
45 YFA054C042ZA Bottom Cover T(1-C)
