ITEM / MODEL
Indoor Unit Outdoor
Main Body CS-A34BB4P CU-
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL51P (Wireless)
Cooling Capacity kW 10.0
BTU/h 34,100
Heating Capacity kW 11.2
BTU/h 38,200
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 26 Me 23 Lo 20 Hi 70
Medium and Low Speed cfm 918 812 706 2471
Outside Dimension (H x W x D) mm 290 x 840 x 840 1220 x 900
inch 11-7/16 x 33-1/24 x 33-1/24 48-7/24 x 35-7/16
Net Weight kg 30 97
lbs 66 214
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20
Compressor
Type, Number of Set - Hermetic-1 (
Starting Method - Direct on-line
Motor Type - 2-pole single
induction
Input kW - Cool/Heat
Rated
Output
kW - 2.8
Fan Type, Number of Set Turbo fan-1 Propeller
Motor Type 6-pole single phase
induction motor
6-pole single
induction
Input kW 0.15 0.24
Rated
Output
kW 0.08 0.055 x
Air-heat Exchanger Slit-fin type Louvre-fin
Refrigerant Control Cool Capillary tube -
Heat - Capillary
Refrigerant Oil (Charged) litre -
Refrigerant (Charged) kg
-
(4.2)
lbs (9.3)
Running
Adjustment
Control Switch Wireless or Wired Remote
Control
-
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
fan motor, Crankcase heater, High and heating
switch, Current transformer
Noise Level Cool dB (A) Hi 45 Me 42 Lo 40 Hi 55
Heat Hi 45 Me 42 Lo 40 Hi 56
16
