Panasonic CS-A18BB4P Service Manual

NO. PART DESCRIPTION QTY. CS-A24BB4P CS-A28BB4P CS-A34BB4P CS-A43BB4P CS-A50BB4P
1 BASE PAN ASS’Y 1 CWD52K1034
2 INNER POLYSTYRENE (TOP) 1 CWG071049 CWG071057
3 INNER POLYSTYRENE (SIDE) 1 CWG07C1016 CWG07C1017
4 CABINET SIDE PLATE ASS’Y 1 CWE04K1001 CWE04K1003
5 CABINET SIDE PLATE ASS’Y 1 CWE04K1002 CWE04K1004
6 FAN MOTOR 1 CWA921049 CWA921050 CWA921051
7 ANTI-VIBRATION BUSHING 4 CWH501016
8 SCREW-FAN MOTOR 4 CWH551032
9 CORD HOLDER 1 CWD74K1001
10 TURBO FAN 1 CWH03K1003
10a NUT for TURBO FAN 1 XNG8
10b SP WASHER 1 XWA8
10c WASHER 1 CWH571008
11 EVAPORATOR 1 CWB30C1112 CWB30C1113 CWB30C1117 CWB30C1118
11a EVAPORATOR SUPPORTER 1 CWD911115 CWD911116
11b EVAPORATOR HOLDER 1 CWD911136 CWD911137 CWD911138
11c EVAPORATOR HOLDER 1 - - CWD911127 CWD911128
11d TUBE ASS’Y (CAPIL. TUBE-EVA) 1 CWT07K1028 CWT07K1018 CWT07K1019 CWT07K1020
12 HEATPROOF TUBE (24) 1 CWG021023
12a HEATPROOF TUBE 1 CWG021021
13 FLARE NUT / (3/8”) / (1/4”) 1 6002140 / (1/4”) CWT25005 / (3/
8”)
13a FLARE NUT / (6/8”) / (5/8”) 1 CWT25004 / (5/
8”)
CWT251012 / (6/
8”)
14 PIPE COVER 1 CWD93C1020
15 SENSOR-EVAPORATOR 1 CWA501047
16 SPRING FOR SENSOR 1 CWH711010
17 DRAIN PUMP COMPLETE 1 CWB53C1003 CWB53C1004
181
