Panasonic CS-A24BD2P Service Manual

Fan Type, Number of Set Turbo fan-1 Propeller
fan
Motor Type 6-pole single phase
induction motor
6-pole single
phase
induction
motor
Input kW 0.09 0.11
Rated
Output
kW 0.04 0.05
Air-heat Exchanger Slit-fin type Louvre-fin
type
Refrigerant Control Cool Capillary tube -
Heat - Capillary
tube
Refrigerant Oil (Charged) litre - MS32 (
1.3)
Refrigerant (Charged) kg
-
(3.8)
lbs (8.4)
Running
Adjustment
Control Switch Wireless or Wired Remote
Control
-
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
thermostat
fan motor, Crankcase heater, High and heating
pressure
switch, Current transformer
Noise Level Cool dB (A) Hi 44 Me 42 Lo 40 Hi 50
Heat Hi 44 Me 42 Lo 40 Hi 53
1. Cooling capacities are based on indoor temperature of 27°C D.B.
(80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B.
(68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F D.B.),
6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50Hz)
ITEM / MODEL
CS-A28BB4P, CU-A28BBP5
Condition by JIS B 8615
Volts V 220 230
240
Phase Single Single
Single
Power Consumption kW Cool 2.69 2.69
2.69
Heat 2.61 2.61
2.61
Running Current A Cool 12.3 12.0
11.7
Heat 12.0 11.7
11.4
Starting Current A 50 52 54
Power Factor % Cool 99 98 96
Heat 99 97 95
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V
50Hz
3.3. CS-A28BB4P / CU-A28BBP8
13
