Panasonic CS-A24BD2P Service Manual

NO. PART DESCRIPTION PART NO. QTY.
1 FRONT GRILLE CWE121026 1
2 COVER-AIR SWING MOTOR CWH811013 1
3 CONNECTOR-SHAFT CWH081002 1
4 CONNECTOR-SHAFT CWH081003 6
5 CONNECTOR-SHAFT CWH081004 6
6 BEARING CWH641006 8
7 VANE CWE241103 4
8 CONNECTOR-SHAFT CWH081005 2
9 CONNECTOR-SHAFT CWH081006 2
10 AIR SWING MOTOR CWA981065 1
11 INSULATION POLYSTYRENE CWG071105 2
12 INSULATION POLYSTYRENE CWG071106 2
13 INSULATION POLYSTYRENE CWG071107 1
14 WASHER CWH571025 16
15 COVER CWD932215 1
16 AIR FILTER CWD001072 1
17 STRING CWH841002 2
18 WASHER CWH571026 2
19 INTAKE GRILLE CWE221067 1
All parts are supplied from MACC, Malaysia (Vendor Code: 086)
32.2. OUTDOOR UNIT
184
