NOTE:
1. Use the main pipe to gain any rise or fall / required for the pipes.
2. The number of bends should be 8 or less in a single system (L + la, L + Ib, L + Ic), and 15 or less
overall.
3. Branch pipes should be positioned horizontally.
- The branch pipe should be horizontal to or perpendicular to the / indoor unit.
