Panasonic CS-A24BD3P

REF.
NO.
PARTS NAME PARTS NUMBER
QUANTITY PER 1
UNIT
CS-
A24BD3P
CS-
A28BD3P
1 Cabinet (Bottom) P02-T05840 1 1
2
Drain pan P42-T02760 1 1
3
Evaporator P45-T05100 1 1
4
Distributor ass’y. P45-T04510 ---- 1
P45-T04670 1 ----
5
Cabinet (Top) P42-T02730 1 1
6
Filter guide ass’y. P42-T02790 1 1
7
Filter P42-T02770 1 1
8
Duct flange ass’y.
(Outlet)
P03-T01370 1 1
9
Fan base ass’y. P45-T05080 1 1
10
Casing R ass’y. P45-T06760 1 1
11
Casing L ass’y. P45-T06770 1 1
12
Fan motor P06-T03481 ---- 1
P06-T03491 1 ----
13
Panel side R ass’y. P42-T02750 1 1
14
Panel side L ass’y. P42-T02960 1 1
15
Terminal board P06-T04680 1 1
16
Capacitor P06-T04630 ---- ----
P06-T04640 1 1
17
Transformer P06-T04300 1 1
18
Remote control (P) A75C2240 1 1
19
Thermistor ass’y. 06-854510 1 1
20
Coil sensor 06-853760 1 1
21
PCB assembly A53D0003A 1 1
22
Noise filter A491018 1 1
(P46-T06120) 1 1
23
PCB fuse (250V
T3.15A)
---- 1 1
All parts are supplied from Taiwan (Tamaco).
