Panasonic CS-A24BD3P - Page 15

ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A28BD3P CU-A28BBP8
Cooling Capacity kW 7.30
(BTU/h) (24,900)
Heating Capacity kW 7.75
(BTU/h) (26,400)
Refrigerant Charge-less m 30
Standard Air Volume for High
Medium and Low Speed
m
3
/min
Hi 25 Hi 43
cfm Hi 883 1518
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Suction
Air Outlet Front blow-out Front blow-
out
Outside Dimension (H x W x D) mm 270 x (1000 + 100) x 650 900 x 900 x
320
Net Weight kg (lbs) 40 (88) 82 (181)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (
Rotary),
Starting Method - Direct on-line
starting
Motor Type - 2-pole single
phase
induction
motor
Input kW - Cool/Heat 2.49/
2.41
Rated
Output
kW - 2.0
Fan Type, Number of Set Sirocco fan-2 Prop. fan-1
Air Volume Control Three-Step and Auto mode
-
(Remote Control)
Motor Type 4-pole single phase induction
motor
6-pole single
phase
induction
motor
Input kW 0.19 0.11
Rated
Output
kW 0.115 0.05
Air-heat Exchanger Louvre-fin type Louvre-fin
type
Refrigerant Control Capillary tube Capillary tube
Refrigerant Oil (Charged) L - MS32 (1.3)
Refrigerant (Charged) kg (oz) - R-22 3.8 (134)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Head Thermostat for compressor, Internal
thermostat
F.M, Crankcase heater, High pressure switch,
Current
Transformer
Noise Level (Sound Pressure) dB (A) Hi 42 Lo 38 50
