Panasonic CS-A24BD3P

REF. NO. PARTS NAME PARTS NUMBER
QUANTITY PER UNIT
CS-A34BD3P CS-A43BD3P CS-
A50BD3P
1
Cabinet (Bottom) P02-T06560 1 1 1
2
Drain pan P42-T02860 1 1 1
3
Evaporator P45-T05340 1 ---- ----
P45-T05350 ---- 1 1
4
Distributor ass’y. P45-T05300 1 ---- ----
P45-T05390 ---- ---- 1
P45-T07040 ---- 1 ----
5
Cabinet (Top) P42-T02830 1 1 1
6
Filter guide ass’y. P42-T02840 1 1 1
7
Filter P42-T02850 1 1 1
8
Duct flange ass’y.
(Outlet)
P03-T01380 1 1 1
9
Fan base ass’y. P45-T05320 1 ---- ----
P45-T05330 ---- 1 1
12
Fan motor P06-T03520 1 ---- ----
P06-T03530 ---- 1 1
13
Stay fan motor P06-T03780 1 1 1
14
Shaft P05-T12620 1 ---- ----
P05-T12630 ---- 2 2
18
Panel side R ass’y. P42-T02750 1 1 1
19
Panel side L ass’y. P42-T02960 1 1 1
20
Terminal board P06-T04680 1 1 1
21
Capacitor P06-T04640 1 1 ----
P06-T04650 ---- ---- 1
22
Transformer P06-T04300 1 1 1
23
Remote control A75C2240 1 1 1
24
Thermistor ass’y. 06-854510 1 1 1
25
Coil sensor 06-853760 1 1 1
26
PCB assembly A53D0003A 1 1 1
27
Noise filter A491018
(P46-T06120)
1 1 1
28
PCB fuse (250V
T3.15A)
---- 1 1 1
All parts are supplied from Taiwan (Tamaco).
29.2. OUTDOOR UNIT
